Graphite® HMI Operator panels

Key Features: HMI Panels Graphite® Operator Panels

Rugged Construction:

Graphite® HMIs have resistive touchscreens and durable aluminum housing, designed for operation in extreme temperatures and high-vibration environments. The 7 and 15-inch models offer sunlight-visible displays for outdoor applications.

Expansion Options:

The plug-and-play modules allow advanced customization, including PID controllers, digital and analog I/O, thermocouples, and universal input modules. The Crimson® Control module enables advanced programming using IEC 61131 standards.

Connectivity:

Graphite® panels include Ethernet, RS-232/RS-422/RS-485 serial ports, and USB connections. Some models feature additional Ethernet and serial port options.

Communication Capabilities:

Supporting over 300 protocols, Graphite® HMIs can manage multi-vendor applications and integrate existing equipment, including PLCs, motion controllers, and PID controllers.

Remote Monitoring and Control:

With an integrated web server, users can monitor and control processes from any networked device. Graphite® HMIs also send email or SMS alerts to ensure prompt responses to issues.

Data Logging:

The built-in data logger records continuous data, events, and alarms, which can be exported as CSV files, emailed, or synchronized with FTP or Microsoft SQL servers.

Crimson® Software:

Red Lion’s Crimson® software simplifies setup with a drag-and-drop interface. It is included at no extra cost, and additional advanced control functions can be added via the Crimson® Control module.

Available HMI Models CR1000 & CR3000Re
